Animated Loading Indicator in Syncfusion Windows Forms Grid

We would like to illustrate how to enable an animated loading indicator for long-running operations in Syncfusion’s GridGroupingControl for Windows Forms. We do this by using a helper that asynchronously uses the .NET framework API ImageAnimator.

The helper, being written in a generic manner, can bind the animated loading indicator to any user interface control of the Control type.



Member Type

Name

Description

Static Method

Wire

Wires the control with the loading indicator and starts the animation.

Static Method

UnWire

Unwires the control from the loading indicator and stops the animation.

Static Property


Gets or sets the animated image with multiple frames.

Table1: LoadingAnimator - Properties and Methods



To wire the loading animator with the control before starting the long-running operation, the following code has to be handled in the respective event.

clip_image001

Using the following code in the respective event, the loading animator can be unwired once the long-running process is complete.

clip_image002

The default, animated image can be replaced with another image through the static Image property.

The following screenshots show the loading animator’s behavior for handling operations like loading, sorting, grouping, and filtering with a large set of records.

clip_image004

;

While Loading Data



clip_image006

After Loading Data

clip_image008

While Sorting by a Column

clip_image010

After Sorting by a Column

clip_image012

While Grouping by a Column

clip_image014

After Grouping by a Column

clip_image016

While Filtering

clip_image018

After Filtering

The link below takes you to a sample that illustrates these operations both programmatically (through menu items at the top) and at the UI level (through user interaction).

AnimatedLoading_GGC.zip
