Vue Box and Whisker chart is used to visualize a group of numerical data through their quartiles. It is also referred as box plot. Box plots may also have lines extending vertically from the boxes (whiskers) indicating variability outside the upper and lower quartiles.
Supports different types of rendering mode such us exclusive, inclusive, and normal.
Represent the values that are lying beyond the minimum and maximum values of the data point with outlier. Usually represented with a circle.
Show meanAllows you to enable or disable the average value of box plot.
Use multiple axes to plot different data sets that widely vary from one other.
Allows you to plot multiple series in a single chart to compare different data sets. Enabling legend and tooltip gives more information about the individual series.
Data labels display information about data points. Add a template to display data labels with HTML elements such as images, DIV, and spans for more informative data labels. You can rotate a data label by its given angle.
Customize the color, thickness, and border of the box plot with in APIs to make it visually unique.
Easily get started with Vue Box and Whisker Chart using a few simple lines of HTML and JS code example as demonstrated below. Also explore our Vue Box and Whisker Chart Example that shows you how to render and configure the chart.
<template>
<div id="app">
<ejs-chart id="container" :primaryXAxis='primaryXAxis'>
<e-series-collection>
<e-series :dataSource='seriesData' type='BoxAndWhisker' xName='x' yName='y'> </e-series>
</e-series-collection>
</ejs-chart>
</div>
</template>
<script>
import { ChartPlugin, BoxAndWhiskerSeries, Category } from "@syncfusion/ej2-charts";
Vue.use(ChartPlugin);
export default {
data() {
return {
seriesData: [
{ x: 'Development', y: [22, 22, 23, 25, 25, 25, 26, 27, 27, 28, 28, 29, 30, 32, 34, 32, 34, 36, 35, 38] },
{ x: 'Testing', y: [22, 33, 23, 25, 26, 28, 29, 30, 34, 33, 32, 31, 50] },
{ x: 'HR', y: [22, 24, 25, 30, 32, 34, 36, 38, 39, 41, 35, 36, 40, 56] },
{ x: 'Finance', y: [26, 27, 28, 30, 32, 34, 35, 37, 35, 37, 45] },
{ x: 'R&D', y: [26, 27, 29, 32, 34, 35, 36, 37, 38, 39, 41, 43, 58] },
{ x: 'Sales', y: [27, 26, 28, 29, 29, 29, 32, 35, 32, 38, 53] },
{ x: 'Inventory', y: [21, 23, 24, 25, 26, 27, 28, 30, 34, 36, 38] },
{ x: 'Graphics', y: [26, 28, 29, 30, 32, 33, 35, 36, 52] },
{ x: 'Training', y: [28, 29, 30, 31, 32, 34, 35, 36] }
],
primaryXAxis: {
valueType: 'Category',
},
};
},
provide: {
chart: [BoxAndWhiskerSeries, Category]
}
};
</script><!DOCTYPE html>
<html>
<body>
<div id="app"></div>
</body>
</html>
Box and Whisker Chart User Guide
Learn the available options to customize Vue Box and Whisker chart.
